OWC ThunderBay Flex 8 Thunderbolt 3 144TB

144TB HDD RAID (8 x 18TB)

Ideal for taming the voracious drive space appetite of RAW, 4K, large format, and VR workflows. Arrives pre-set with RAID 5 speed and protection. Plus, select a recommended PCIe card or add your own.

• Storage Solution #1: 144TB HDD RAID
• RAID Management: OWC SoftRAID
• PCIe Expansion Slot
• 8 Port Dock

8 ENTERPRISE-CLASS HARD DRIVES
Edit and store entire projects on this ultra-capacity HDD RAID array that arrives pre-certified in RAID 5 for the best balance of data integrity and performance. Or, setup the RAID of your choice with flexible user configurable RAID 0, 1, 4, 5, 1+0 (10) options.

OWC SoftRAID
Experience easy-to-use RAID flexiblity, access to new drive technologies such as M.2/U.2 NVMe solid-state drives, and upgrade your system in the future with ease. OWC SoftRAID offers cost-effective uncompromised performance with unparalleled flexiblity. Works interchangeably on your Mac and Windows PC.

Add Hardware RAID
For specialized needs such as using SAS drives or data encryption for security reasons.

8 HDD Maximum Capacity Configuration
Ideal for taming the voracious drive space appetite of RAW, 4K, large format, and VR workflows. Arrives pre-set with RAID 5 speed and protection. Plus, enjoy docking convenience and expand your capabilities by selecting a recommended PCIe card or add your own.

Flex Your Way Through Every Workflow
Whether you call it a workflow workhorse, a productivity platform, or a configurable command center, one description of the ThunderBay Flex 8 says it best. It is a groundbreaking workflow solution for digital imaging, VFX, video production, and video editing professionals from the world’s leading Thunderbolt accessory manufacturer.

ThunderBay Flex 8 offers eight drive bays that support a mix of SATA/SAS1 and U.2/M.22 NVMe drives for virtually limitless storage capacity. Next, there’s a plethora of ports including two Thunderbolt 33, one USB-C, and two USB-A for device docking and charging.

See your work in greater detail by adding up to an 8K display4 via a built-in DisplayPort 1.4 connection. Ingest hi-res images and video via front-side SD 4.0 and CFexpress card readers. And when you want to expand your desktop capabilities, there’s a PCIe slot waiting for your specific project needs.

ThunderBay Flex 8 is the one Thunderbolt 3 desktop device that rules them all. With an irresistible economy of scale, this consolidated solution is ideal for anyone waiting for the right moment to invest in Thunderbolt technology.

NVMe. PCIe. What’s It Mean to Me?
At the heart of the ThunderBay Flex 8 capabilities are two cutting-edge technology standards: NVMe and PCIe. Non-Volatile Memory Express (NVMe) optimizes the performance of modern flash technology over the Peripheral Component Interconnect Express (PCIe) standard. It enables significantly faster SSD performance with a more direct and optimized path to a computer’s processor.

Tying both of these technologies together is the Thunderbolt 3 interface which uses the PCIe bus. This interface offers the fastest data transfers possible on a single cable between computers and peripherals like storage solutions, docks, and expansion devices while also supplying 85W of power to keep your laptop ready to go at a moment’s notice.

Muscle-FLEXing Data Performance
Right out of the packaging, all eight bays are configured with SATA 6Gb/s 3.5-inch HDDs. With real-world read/write speeds of 2750MB/s that saturates the Thunderbolt 3 speed threshold, you’re ready to handle 4K/8K and even Phantom high-speed files.

Done with the drives but need the docking connectivity?

Eject the ThunderBay Flex 8 drives and any external drives in a single click with the free OWC Dock Ejector app. It ensures all data has been written before any drive is unmounted to protect against data loss. It will even warn you from accidentally ejecting an in-use drive.

Docking FLEXibility
A virtual buffet of productivity-enhancing possibilities awaits you with the docking connections built into ThunderBay Flex 8. Power your notebook with up to 85W power delivery while capturing multi-stream hi-res footage at full frame rate. Connect audio and video mixers, digital camera, keyboards, and other peripherals and charge mobile devices via one USB-C and two USB-A 10Gb/s ports. Ingest and work with 4/8K RAW video and RAW photo files immediately at speeds up to 985MB/s with frontside SD 4.0 and CFexpress card readers. Add more viewing space with up to an 8K monitor via the DisplayPort 1.4 interface. And if all that’s not enough to satisfy your project needs, daisy-chain up to five additional Thunderbolt 3 devices!

FLEXpandable for Unique Needs
By removing the enclosure’s side panel, you can expand your capabilities by installing a half-length, full-height, single-width expansion card in the PCIe x16 connector/x4 lanes slot. Add a 4K video capture card for direct ingest of multi-stream high-res footage. Record high-quality tracks with an audio card and then edit and archive tracks.

Create a powerful file server with a high-speed networking card. By replacing the built-in SATA drive controller with a SATA or SAS RAID card, you can turn ThunderBay Flex 8 into a hardware RAID storage solution while keeping a PCIe slot open for other cards.

SoftRAID: RAID Made Easy
Harness the full capability of your OWC drive array with the included SoftRAID XT, the most powerful, intuitive RAID management software on the market for macOS and Windows. SoftRAID’s RAID creation and management technology has been finely tuned to perfection with over 20 years of development to provide rock solid protection of your data and optimize drive performance.

SoftRAID XT provides an unbeatable combination of speed, protection, and compatibility:

• Advanced: Create RAID 0/1/4/5/1+0 (10) arrays
• Protected: SoftRAID Monitor constantly watches your disks and alerts you if problems are detected
• Validated: Volume validation ensures sectors can be read and parity is correct
• Certified: Checks disks before use to ensure they are safe for data storage
• Vigilant: Error prediction helps protect against unexpected failure
  Universal: Move SoftRAID arrays seamlessly between Mac and PC2 with built-in OWC MacDrive technology

Beyond Hardware RAID
SoftRAID provides a level of storage performance that you simply can’t get with hardware RAID. SoftRAID gives you increased power and control over your RAID drives and disks that hardware RAID can’t deliver and doesn’t lock you into technology that you can’t upgrade or expand.

A Protective, Economical Post-Production Solution
Sending a drive from set to post-production typically entails tedious and time-consuming drive enclosure disassembly to access the storage drive or costly shipping of the entire enclosure to the post lab. But ThunderBay Flex 8 offers yet another option.

By installing an OWC U.2 NVMe Interchange System carrier tray (sold separately) with a built-in U.2 connector into a ThunderBay Flex 8 drive tray, you can protect the U.2 SSD drive’s connector from repeated install/removal wear for improved drive longevity and investment. When done with your shoot, just ship the lightweight protective carrier and drive to the lab where the carrier can be installed into an OWC Helios 3S equipped with the OWC Interchange System. It’s a complete solution to safeguard your data while lowering shipping costs.

FLEX On-Set
OWC Interchange System Carrier Tray with SSD
OWC ThunderBay Flex 8
Protects U.2 SSD drive connectors from install/ removal wear to improve drive longevity and extend your drive ROI.

Transit to Post
OWC Interchange System Carrier Tray with SSD
Small and economical. Ship only what you need.
Lightweight protective carrier safeguards data while lowering shipping costs vs shipping the entire enclosure.

Post-Production Lab
OWC Interchange System Carrier Tray with SSD
OWC Helios 3S (sold separately)
OWC Interchange System (sold separately)
Desktop U.2 NVMe SSD swappable storage for fast processing of footage.
